Compression: Standard H.265 High Profile
CPU: Cortex A9
OS: Embedded Linux
Video Input: BNC × 4
TVI/AHD : 5MP/4MP/3MP/1080P/720P/WD1
CVI : 4MP/3MP/1080P/720P/WD1
IP Input: 2CH ( Up to 6CH )
HDMI × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
BNC × 1 : CVBS ( used as the main or spot output )
Audio Input: RCA × 1
Audio Output: RCA × 1
Record Resolution: 5MP Lite/4MP Lite/1080P/1080P Lite/720P/WD1
5MP Lite :10fps
4MP Lite : 12fps (PAL)/15fps (NTSC)
1080P : 12fps (PAL)/15fps (NTSC)
1080P Lite/720P/WD1 : 25fps (PAL)/30fps (NTSC)
IP Input Resolution: Up to 5MP@25fps
Playback: 4 CH
Network Interface RJ45 100Mbps × 1
Protocol: TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Mobile Device OS: iOS, Andriod
HDD: SATA × 1, up to 6TB
RS485: RS485 × 1, connect to PTZ or keyboard
USB: USB 2.0 × 2 ( in the rear panel )
Power Supply: DC12V / 1.5A
Consumption: ?5W( without HDD)
Work Environment: -10 ? 50 ??10% ? 90% humidity
